Silver Hollow Conductor with Different Wall Thickness

This product has complex process, high processing difficulty,unequal adjacentwall thickness, deviation of more than 2mm, high accuracy of outer diameter and inner hole size, ensuring uniform and sufficient flow of internal cooling liquid, and the maximum processing length of a single wire can reach 10mm.

Inquire Now NEXT PRODUCT

Technical Specifications

Parameter	Value / Description
Product Name	Silver Hollow Conductor with Different Wall Thickness
Material	Silver-Bearing Oxygen-Free Copper (CuAg)
Silver Content	0.07% – 0.12%
Copper + Silver Purity	≥ 99.99%
Oxygen Content	≤ 10 ppm
Electrical Conductivity	≥ 98% IACS
Wall Thickness Configuration	Unequal adjacent wall thickness
Wall Thickness Deviation	≥ 2 mm (difference between adjacent walls)
Outer Diameter Tolerance	± 0.03 mm (customizable)
Inner Hole Diameter Tolerance	± 0.05 mm (customizable)
Maximum Single Wire Length	10 meters (standard) / Longer upon request
Surface Condition	Bright, clean, oxidefree
Bend Performance	Excellent ductility for coil winding

Applications

Large Turbo‑Generator Rotor Windings — Where asymmetric cooling is required to balance thermal loads.

High‑Field Electromagnets — For physics research, MRI systems, and particle accelerators.

Specialized Induction Heating Coils — Requiring internal liquid cooling with non‑uniform heat distribution.

Custom Electrical Busbars — With integrated cooling channels for confined spaces.

FAQs

Q1: Why is the adjacent wall thickness intentionally unequal?

The unequal wall design allows engineers to direct more coolant flow to specific areas of the conductor that experience higher thermal loads, or to accommodate asymmetric slot geometries in the rotor. This ensures uniform cooling efficiency across the entire winding.

Q2: What does "deviation of more than 2mm" mean in practice?

It means the difference in wall thickness between two adjacent sides of the hollow profile can exceed 2 mm. For example, one wall may be 4 mm thick while the adjacent wall is 6.5 mm thick. This asymmetry is precisely controlled to meet customer specifications.

Q3: How do you maintain high accuracy on OD and ID with such complex asymmetry?

We utilize multi‑axis laser measurement systems (ODAC/UMAC) and custom‑designed drawing tooling. Real‑time feedback adjusts die position during processing to ensure both outer geometry and inner hole dimensions remain within specified tolerances.

Q4: What is the maximum single wire length available?

The standard maximum single wire length is 10 meters. Longer lengths may be available depending on the specific cross‑sectional dimensions and wall thickness configuration. Please inquire with your requirements.

Q5: Can this product be bent or formed for coil winding?

Yes. Despite the asymmetric wall thickness, the silver‑bearing copper material offers excellent ductility and can be bent and formed using standard winding equipment without cracking or deformation of the internal channel.
