Trapezoidal Copper Platoon (Small)

This product has high technical content, especially the extremely low oxygen content, which can reach below 5ppm, and the copper+silver content is above 99.99%. It has high electrical conducti vity, and the electrical conductivity reaches 101 (IACS%). The diameter is 18 mm and can be bent for 120 degrees without any crack.
Oxygen Content: ≤ 5 ppm — Virtually oxygen-free, eliminates hydrogen embrittlement risk

Copper + Silver Purity: ≥ 99.99% — Near absolute purity

Electrical Conductivity: 101% IACS — Exceeds international annealed copper standard

Diameter: 18 mm (smaller diameters available upon request)

Bend Capability: 120° bend without surface cracking

Inquire Now NEXT PRODUCT

Technical Specifications

Parameter	Value / Description
Product Name	Trapezoidal Copper Platoon (Small)
Material Grade	High-Purity Oxygen-Free Copper (Cu-OFE)
Copper + Silver Content	≥ 99.99%
Oxygen Content	≤ 5 ppm
Electrical Conductivity	101% IACS (Minimum)
Diameter	18 mm (standard) / Smaller sizes available
Diameter Tolerance	± 0.05 mm
Bend Performance	120° bend without cracking
Tensile Strength	220 – 260 MPa (Annealed)
Elongation	≥ 35%
Surface Condition	Bright, clean, oxide-free
Packaging	Spools, coils, or custom packaging

Applications

Superconducting Magnet Current Leads

High-Energy Physics and Particle Accelerator Components

Medical Imaging Systems (MRI, NMR)

High-Frequency Induction Heating Coils

Vacuum Furnace and Cryogenic Components

Aerospace Power Distribution Systems

Precision Welding Electrodes

FAQs

Q1: What does 101% IACS conductivity mean?

IACS (International Annealed Copper Standard) defines 100% as the conductivity of pure annealed copper. 101% IACS indicates conductivity 1% higher than the standard reference, achievable only through extreme purity and optimized processing.

Q2: Why is oxygen content below 5 ppm critical?

In hydrogen-rich or high-temperature environments, copper with higher oxygen can undergo hydrogen embrittlement, causing internal cracks. Oxygen ≤5 ppm eliminates this risk.

Q3: Can this product bend 120° without cracking?

Yes. The material undergoes a specialized annealing process that imparts excellent ductility, allowing a 120° bend under standard practices without surface cracking.

Q4: What does "(Small)" indicate?

"(Small)" designates this as the standard 18 mm diameter variant within our smaller-diameter precision conductor series. Custom smaller diameters are available upon request.

Q5: Do you offer custom sizes or shapes?

Yes. We can customize diameter, cross-sectional shape, purity, temper, and length. See the Customization Capabilities section for details.
